BRL80 Liquid Metal
Extreme High-Performance Liquid Metal
BRL80 is a liquid metal alloy designed for high performance CPU and GPU that need to deliver even higher performance with constant high computing power. These applications range from gaming and extreme overclocking to high performance server systems that require fast heat dissipation at the same time.
![](https://www.buzrise.com/wp-content/uploads/2023/06/5years-150x150.png)
5 Years Durability
![](https://www.buzrise.com/wp-content/uploads/2023/06/alcoholpad-150x150.png)
Alcohol Pad Included
![](https://www.buzrise.com/wp-content/uploads/2023/06/swabs-150x150.png)
2 Cotton Swabs
High Thermal Conductivity
BRL80 series is a liquid metal alloy that features high thermal conductivity and low thermal resistance.
High cooling performance can be achieved when using this liquid metal paste. BRL80 series can provide optimal and very fast performance even at high temperatures. One of the advantages of liquid metal alloys are, fast and efficient heat dissipation, which is especially important for high performance processors or graphics cards.
Another advantage is the high thermal conductivity, which is designed for very high computing power for possibly temporary even higher computing power, which can lead to very high temperatures, which must then be dissipated quickly so as not to endanger the system stability.
![](https://www.buzrise.com/wp-content/uploads/2023/06/buzrise_cpu_liquid-metal-1024x621.jpg)
![](https://www.buzrise.com/wp-content/uploads/2023/06/brl80-p-1024x1024.jpg)
Specifications
Thermal Conductivity | ≤80W/m.k |
Density | 6.44 g/cm³ |
Electrical Conductivity | 3.46×106 S/m (at 20° C |
Boiling Point | >1,300° C |
Melting Point | 6-10° C |
Operating Temp. | 5500C |
Minimal BLT | 25-30 |
Viscosity | 230 Pas |
Thermal impedance@ 40psi / 0.08mm | 0.0061 °C‐in2/W |
Typical Applications
- PC Peripherals /EXTREME Overclocking and Gaming Systems, High-Performance CPU and GPU, Gaming Consoles PS3/PS4/PS5, XBOX ONE
- HIGH END Server Systems and Network SYSTEMS
- AV High End and Laser Display Technology
- 3D Equipment and Laser Printing
- AEROSPACE
Features
- HIGH Thermal conductivity: up to ≤80.0W/MK
- Low Thermal Resistance at low pressure
- High Cooling Performance
- Ultra Low Bond Thickness
- Good Application, Low Viscosity
- No corrosion or oxidation to any contact Surfaces
- Doesn ́t dry out.
- It is electricaly conductiv
- 100% ROHS Compliant, Not Toxic
- Usage Guarantee Up to Ten Years Shelf Live
